FL2 Horizontal Shunt
Horizontal diverter: HoFL2 ● Rated current: 20A~1000A ● Rated voltage drop: 75mV ● Product accuracy: 0.1%~5% ● Accept customization
Series：
Keywords：
FL2 Horizontal Shunt
1. Electron beam welding process, more accurate sampling point for screw hole design
2. High reliability, high overload capacity and high product accuracy.
3. Wide temperature range non-inductive design
4. Resistance temperature coefficient TCR × 10-6/℃≤50ppm
5. Products meet ROHS requirements
6. The whole series of products comply with the vehicle specification AEC-Q200 test.
1. Product nominal:
HoFL2-100A-75mV-0.5%
| manufacturer | Product range | Rated current | Rated voltage drop | accuracy | Product color |
| Ho milliohm electron | FL2 series | 20A | 75mV |
0.1% 0.2% 0.5% 1% 2% 5% |
Yellow (non electroplating) Silver (electroplating) |
| 50A | |||||
| 100A | |||||
| 200A | |||||
| 300A | |||||
| 400A | |||||
| 500A | |||||
| 600A | |||||
| 1000A | |||||
| 2000A |
| Rated Current | 20A~2000A |
| Pressure drop | 75mV |
| AccuracyClass | 0.1%、0.2%、0.5%、1%、2%、5% |
| 20 ℃~60 ℃ resistance temperature coefficient T.C.R ( ppm / ℃ ) | ≤50 |
| Manganese copper material | GB 6J12 precision manganese copper 50ppm |
| Copper material | GB T2 Y2 |
| Operating Temperature Range | -55℃~+170℃ |
