FL3 Horizontal Shunt
Horizontal diverter: HoFL3 ● Rated current: 100A~600A ● Rated voltage drop: 75mV ● Product accuracy: 0.2%~5% ● Accept customization
Keywords：
FL3 Horizontal Shunt
1. Electron beam welding process, more accurate sampling point for screw hole design
2. High reliability, high overload capacity and high product accuracy.
3. Use non-inductive design with wide temperature range and inductance less than 10 Ohms
4. Resistance temperature coefficient TCR × 10-6/℃≤50ppm
5. Products meet ROHS requirements
6. The whole series of products comply with the vehicle specification AEC-Q200 test.
1、Product nominal:
· HoFL3-100A-75mV-0.5%
| manufacturer | Product range | Rated current | Rated voltage drop | accuracy |
| Ho milliohm electron | FL3 series | 100A | 75mV | 0.2% 0.5% 1% 2% 5% |
| 200A | ||||
| 250A | ||||
| 300A | ||||
| 400A | ||||
| 500A | ||||
| 600A |
| Rated Current | 100A~600A |
| Pressure drop | 75mV |
| AccuracyClass | 0.2%、0.5%、1%、2%、5% |
| Resistance temperature coefficient T.C.R ( ppm / ℃ ) | ≤25 |
| Manganese copper material | GB 6J12 precision manganese copper |
| Copper material | GB T2 Y2 |
| Operating Temperature Range | -50℃~+170℃ |
